Streeter

In “Master Sky” you can buy street payment terminal “Streeter”. It is highly waterproof and vandal-resistant.

The "Streeter" payment kiosk is designed for an outdoor floor-mounted installation.

The self-service kiosk has a reinforced anti-vandalous case, protected from the humidity and dust, also equipped with a safe for the bill acceptor. The street kiosk is capable of working in any weather conditions.

Reinforced anti-vandalous steel case
New door opening mechanism, significantly increasing the break-in resistance
Operating in any weather conditions
Individual set of options and components available

Vandal resistant housing
Vandal-resistant case and special door opening mechanism exclude the possibility of tampering with the device from the outside.

Safe for the bill acceptor
The bill acceptor is located in a separate area, which does not require access of service engineers, and the safe reliably protects cash from intruders.

Payment equipment
Coupon and coin acceptor allows you to make payment transactions with any type of cash.

Monitor with touch panel
The device interface and touch panel allows the user to make inquiries and enter data as quickly and conveniently as possible.

Check printing
High-quality thermal printer allows printing fiscal checks and issuing receipts for transactions.

Possibility of individual set of options and accessories
At your request we will install the necessary equipment to solve your business tasks.

Dimensions:

Width: 578 mm
Height 1780 mm
Depth: 450 mm
Packed volume: 0.25 m3
Power consumption: 310 W
Power supply: 220 V

The "InWall" payment kiosk

In The Master Sky, you can buy the "InWall" payment kiosk. This payment kiosk is designed to be mounted into the walls of the buildings and offices, entrance areas and shop windows.

The "InWall" payment kiosk is designed to be mounted into the walls of the buildings and offices, entrance areas and shop windows.

Reinforced anti-vandalous steel case
Works in any weather conditions
Individual set of options and components available

Configuration
Bill acceptor	+
Thermal printer	+
Modem	+
Monitor	+
Touch panel	+
System block	+
Power supply unit	+
Heating	+
Bill acceptor safe	+
RAL painting	+
Optional equipment
Coin acceptor	+
Barcode scanner	+
UPS	+
Security alarm	+

Dimensions:

Width - 715 mm
Depth - 650 mm
Height - 1880 mm
Weight - 170 kg

Card Dispenser

In “Master Sky” you can buy Self-service device for issuing bank and payment cards - Card Dispenser. Autonomous and reliable Card Dispenser, made of high-strength materials, provides long service life and stable operation.

The cartometer, made of highly durable materials, ensures long life and stable operation even in remote locations thanks to LTE support. Maintenance of the device does not require a specialist and can be easily performed by any employee.

Ability to segment cards by compartment
Video cameras with biometrics
Forgotten card compartment
Large touch screen

Ability to segment cards by compartment
Self-service device functionality allows you to differentiate your offers to users into credit, debit and premium cards.

Video cameras with biometrics
High-definition cameras and Face ID identification will leave no chance for attackers to fool the system with someone else's credentials.

Forgotten card compartment
The security of even the most absent-minded customers is guaranteed by a separate lost card compartment: if a user forgets to retrieve a card, it is automatically routed to a separate compartment.

Large touch screen
With multi-language and a well thought-out UX - the customer can easily find the right buttons and understand what to do next.

Dimensions:

Width - 500 mm;
Depth - 535 mm;
Height - 1830 mm;
Weight - 140 kg.

Instant Сard Issuance Kiosk "Matic"

In “Master Sky” you can buy self-service device for issuing bank and payment cards - Instant Сard Issuance Kiosk "Matic". Autonomous and reliable card dispenser "Matic", made of high-strength materials, provides long service life and stable operation.

The "Matic" Instant Сard Issuance Kiosk, made of highly durable materials, ensures long life and stable operation even in remote locations thanks to LTE support. Maintenance of the device does not require a specialist and can be easily performed by any employee.

Ability to segment cards by compartment.
Video cameras with biometrics.
Compartment for forgotten cards.
Large touch screen.
Fast production of personalized bank cards

Возможность сегментирования карт по отсекам

Функционал устройства самообслуживания позволяет разграничить ваши предложения для пользователей на кредитные, дебетовые и премиум карты.

Видеокамеры с функцией биометрии

Камеры повышенной четкости и идентификация по Face ID не оставят шансов для злоумышленников обмануть систему по чужим документам.

Отсек для забытых карт

Безопасность даже самых рассеянных клиентов гарантируется отдельной ячейкой для утерянных карт: если пользователь забыл получить карту — она автоматически направляется в отдельную ячейку.

Большой сенсорный экран

С мультиязычностью и продуманным UX — клиент без труда найдёт нужные кнопки и поймёт, что ему делать дальше.

Быстрое производство именных банковских карт

Продвинутый эмбоссер — менее, чем за минуту создаст индивидуальную карту для клиента, четко пропечатав данные на заготовку и исключив возможность брака.

Dimensions:

Width - 357 mm;
Depth - 425 mm;
Height - 1000 mm;

The "APP PRO" payment kiosk

In The Master Sky, you can buy the "APP PRO" payment kiosk. It combines reliability and modern design.

The APP Pro payment terminal combines a modern design that fits perfectly into any room. Thanks to a well thought-out design with a convenient arrangement of modules, the device occupies a minimum of space and provides easy maintenance.

Payment equipment
RGB Lighting
Touchscreen
Receipt printing
Personalization

Payment equipment

A bill acceptor and coin receiver allow for cash operations.

RGB Lighting

Your device will be highlighted among competitors and in the general space of the location.

Touchscreen

The device’s UI and touchscreen enable users to quickly form requests and enter the data.

Receipt printing

A high-quality thermoprinter can print fiscal receipts and issue bills for executed operations.

Personalization

All equipments can be installed according to your demands and your business needs.

Dimensions:

Width: 585 mm.
Height: 1369 mm
Depth: 351 mm
Power consumption: 310 W
Power supply: 220 V

"Spider" kiosk

In "Master Sky", you can buy the "Spider" payment kiosk. It is designed to be mounted on the walls.

The "Spider" payment kiosk is designed to be mounted on the walls of the buildings, shopping pavilions, tents in places with high pedestrian traffic. It is compact and attractive. Highly resistant to vandalism and breaking in.

The most reasonable price while maintaining quality and reliability
Minimal space requirement
Simple and convenient maintenance
Individual set of options and components available

Payment equipment
Coupon and coin acceptor allows you to make payment transactions with all types of cash.

Monitor with touch panel
The device interface and touch panel allows the user to make inquiries and enter data as quickly and conveniently as possible.

Check printing
High-quality thermal printer allows printing fiscal checks and issuing receipts for transactions.

Possibility of individual set of options and accessories
On your request we will install the necessary equipment to solve your business tasks.

Dimensions:

Width - 520 mm;
Depth - 369 mm;
Height - 100 mm;
Weight - 40 kg.

“UN-4” payment kiosk

In The Master Sky, you can buy the “UN-4” payment kiosk. A modern stand-alone payment device with a high degree of protection against vandalism and reliable safe locks.

Payment terminal “UN - 4” Compact and affordable payment kiosk with easy maintenance, saves space and provides quick replacement of consumables.

Payment equipment
Monitor with touch panel
Check printing
Separate collection and service areas
Possibility of individual set of options and accessories

Payment equipment

Coupon and coin acceptor allows you to make payment transactions with any type of cash

Touch panel monitor

Multifunctional stand-alone interface and responsive input and output modules will save users' time

Check printing

High-quality thermal printer allows printing fiscal checks and issuing receipts for transactions made

Separate collection and service areas

The safe with cash is placed so that all service is carried out outside the zone of access to it.

Possibility of individual set of options and accessories

At your request we will install the necessary equipment to solve your business tasks.

Dimensions:
Width - 540 mm;
Depth - 540 mm;
Height - 1460 mm;
Weight - 120 kg.

APP “Econom” payment kiosk

In The "Master Sky", you can buy the APP "Econom" payment kiosk. The Econom payment kiosk has a compact size and allows customers to pay for the company services using coins.

The Econom payment kiosk has a compact size and allows customers to pay for the company services using coins. Coin acceptor offers the kiosk owner the opportunity of expanding the range of customers, in certain cases increasing the number of payments at the location, and not limiting the minimal amount of the payment. This is especially effective when developing in the regions.

The most reasonable price while maintaining quality and reliability
Minimal space requirement
Simple and convenient maintenance

Individual set of options and components available

Configuration
Bill acceptor	+
Thermal printer	+
Modem	+
Monitor	+
Touch panel	+
System block	+
Power supply unit	+
RAL painting	+
Optional equipment
Coin acceptor	+
Barcode scanner	+
Heating	+
UPS	+

Dimensions:
Width: 555 mm.
Height: 1290 mm
Depth: 390 mm
Weight: 60 kg
Power consumption: 310 W
Power supply: 220 V

The MINDEO CR40-2D (Ring) barcode scanner

In The Master Sky, you can buy the Mindeo CR40 2D ring scanner. The scanner reads common 1D/2D barcodes - both printed and from mobile devices screens.

The Mindeo CR40 1D Bluetooth ring scanner has an ergonomic and stylish design for comfortable scanning: it fits comfortably in your hand without interfering with other tasks. With 3 types of reading indication - light, sound and vibration - it provides instant feedback every time you scan. The scanner reads all common linear barcodes.

The scanner reads common 1D/2D barcodes - both printed and from mobile device screens, with a density from 4 mils. That's why the 2D version easily recognizes not only standard barcodes but also high-density barcodes used for new labeling of tobacco products, medicines, clothes, shoes, and alcohol.

The scanner is compatible with different types of equipment (computers, smartphones, tablets, etc.) running on different operating systems: Windows, Android and iOS, and easily connects to the selected device via Bluetooth 4.0 wireless technology, providing data transfer to the main device within 30 meters of the line of sight.

The CR40 can store more than 3000 barcodes until the data can be transferred to the inventory system, and a 380 mAh battery guarantees up to 5 hours of continuous work without recharging.

The model can work for up to 5 hours even if operations require a permanent Bluetooth connection and/or intensive scanning. The scanner can stay in standby mode for up to 48 hours.

The scanner can withstand multiple drops on concrete floor from a height of 1 meter. It is well protected even when used in moderately harsh conditions.

Ergonomic, lightweight, non-slip design and 180° rotation support
380 mAh Li-ion battery, 6 hours of steady usage time
Bluetooth 4.0, operating range up to 30 meters
Supports autonomous accumulation of up to 3000 barcodes
Compatible with Windows, Android, iOS devices (such as computers, smartphones, tablets, etc.).

Scanner shape factor: Ring scanner
Barcodes readable: 2D
Scanner interface: Multi-interface
Communication: Bluetooth
Scanner reader type: 2D
Reading distance (cm): 2 to 48.5 cm
Drop resistance: 1 m
Resolution (mil): 1D: 4 mil Code 39, 2D: 6.7 mil PDF4 17

Dimensions: 5.26 x 3.6 x 4.7 cm

Glass touch infrared Zaagtech 19

In The Master Sky, you can buy the Zaagtech 19" infrared touch glass for payment and banking kiosks.

The ZaagTech 19" infrared touch frames - the new word in touch technology that transforms LED screens into an interactive surface.

One-piece construction with frontal protection IP65
Immunity to ambient light up to 150,000 lux
Recognition of objects up to 6mm
Auto diagnostics
Possibility of HID connection (without driver installation) for Windows/Android.

Screen Diagonal: 19 "
Touch screen technology: Infrared
Multi-touch: Yes
Number of multi-touches: 4
Accuracy of touch indication: 1.0 mm
Sampling frequency: up to 150 fps
Touchscreen controller interface: USB
Screen format (Aspect Ratio): 5:4
Frame thickness: 7.5 mm
Glass thickness: 3 mm
Touch response time: less than 10 msec
Optical transparency: over 90%
Touch screen resolution: 32768 x 32768
Supported operating systems: Windows®7, Windows®8,Windows10, Vista, XP, Mac® OS, Linux, Android
Power supply: via USB
Working temperature: -20° to +70° C
Storage temperature: -40° to +85° C
Cleaning: Water, isopropyl alcohol and similar non-abrasive cleaners
