PIN pad Cryptera EPP 1217

In Master Sky you can buy one of the most popular models of PIN-pads - Cryptera EPP 1217

EPP 1217 is one of the most popular models of PIN-pads. It is the top model in the CRYPTERA PIN-pads lineup and is the most secure device available on the market today. EPP 1217 is adapted for use in self-service terminals, ATMs and gas stations. It is protected against fraudulent attacks and guarantees secure payment. The design of the PIN pad meets all ergonomic requirements.

Main features:

  • Vandal-resistant polymer housing
  • Engraved stainless steel keys
  • Meets ergonomic standards
  • Custom embossing Embossing
  • Battery in separate compartment
  • Data protection system for battery replacement
  • Faceplate size matches NCR ATM mounting locations
  • PCI PED 1.0, 2.0, 3.0 certification for Online applications
  • RoHS certified

Model: EPP 1217

Lifetime: 2,000,000 keystrokes

Encryption algorithms: RKL, DES, 3DES, RSA, MAC

Key distribution scheme (3DES): DUKPT, MK/SK, Fixed

RS232: RJ-45 based RS232-D up to 115200 bps

USB: Connector, emulates RS232 port (free driver)

Diagnostics: 3 LEDs

Front panel sealing: Yes

Vandalism: IK07

Certificate: CE

Waterproof: IP64

PCI Certificate: 1.0, 2.0, 3.0

External dimensions: 112 * 160 * 30

Power supply: 12V +/- 20%, max 100mA

Operating temperature: -25...+45⁰C (without heating)

OTI UNO 8 card reader

In Master Sky you can buy miniature modular readers for cashless payments via FeliCa and NFC technology on levels 1 and 2 - OTI UNO 8.

Due to its unique size, the UNO-8 is considered the world's smallest modular FeliCa and EMVCo Level 1 and Level 2 certified reader. It also supports other NFC-based contactless payment systems such as Mifare and P2P.  The UNO-8 features full contactless connectivity and multiple installation options. It is designed for self-payment systems including ATMs, advanced electric vehicle charging points, ticket vending machines, toll collection, gambling machines, kiosks, access control points and public transportation.



  • EMVco L1, L2 contactless EMV (modular - Visa & Mastercard cores)
  • NFC and BLE connectivity**
  • Supports Felica™ and Mifare
  • ISO18092 P2P
  • Multiple SAM connectors



  • Installation options:
  1. surface mounted
  2. embedded
  • Supports USB powered configuration
  • IP IP IPX5 indoor/outdoor installation

EMVCo

  • Contactless EMV L1
  • Contactless EMV L2*
  1. EMVCo C2 core (MasterCard)
  2. EMVCo C3 core (Visa)

Additional payment applications

  • Apple Pay
  • Android Pay
  • MasterCard PayPass M/Chip V3.0.3 (including Data Exchange)
  • MasterCard PayPass Mag-Stripe V3.3
  • NDOT over MasterCard - for transportation

RF Interface

  • RF Carrier Frequency: 13.56 MHz
  • RF Output: 450mW
  • ISO/IEC 14443 A&B and Mifare: Full compliance
  • ISO/IEC 15693 Vicinity: Optional
  • FeliCa: +
  • P2P: +
  • Micro SIM Push-Push Interface: +
  • Communication Links: USB, RS232

USB:

  • 2.0 Full Speed: HID + MSD
  • Connectors:  Standard mini-USB connector
  • USB Only: Mini USB connector
  • Full Interface: JST 10 pin P/N BM10B-ZPDSS

Indicators:

  • LEDs: Four programmable on-board LEDs +RGB logo LED
  • Buzzer: Speaker
  • Electronic Board Power Requirements:
  • 8VDC – 45VDC: On-board switching power supply
  • 5VD: From USB bus in USB only
  • Maximum Power Consumption: 2W (RF signal ON)

Mechanical:

  • Dimensions: H – 78.6, W – 61.0, D –  21.3
  • Weight: 125 gr.

Temperature:

  • Operating: -20°C to 70°C (-4°F to 158°F)

Environment:

  • Vibrations: 10 ÷ 200 Hz @ 2.0G
  • IP Rating: IPX5
OTI UNO 6 card reader

In Master Sky you can buy contactless reader based on NFC technology and for Apple Pay™ systems for self-service and applications - OTI UNO 6.

Contactless reader based on NFC technology and for Apple Pay™ self-service and app-based systems

The UNO-6 miniature reader is designed specifically for ATMs and self-service retail payment machines, including:

  • ATM - automated teller machines and banking devices
  • AVM - vending machines
  • Ticket vending machines
  • Toll road toll collection machines
  • Slot machines and gambling machines
  • Self-service kiosks
  • Micro market toll booths
  • Access control
  • Terminals for public transportation passenger access

Possibilities

  • Installation options:
  1. on enclosure externally
  2. tapping into enclosure
  3. fixed
  • Specially designed for custom frame installation
  • Supports Apple Pay, Android Pay and Samsung Pay
  • Supports USB powered configuration
  • IP X5 indoor and outdoor installation
  • Supports offline PIN verification
  • Voltage from 8 V to 45 V DC or 5 V DC from US Bus
  • Communication Interfaces: USB 2.0 / RS232 / RS485 / TTL:
  1. Mini-USB connector (USB 2.0).
  2. Full JST interface connector with 10 pins BM10B-ZPDSS.

EMV

  • Contactless EMV L1

VISA

  • VISA PayWave MSD V2.1.3
  • VISA PayWave qVSDC V2.1.3
  • NDOT over VISA - for transportation
  • VISA Global Transit Payment V1.2 - pilot specification
  • VISA Pilot Visa PayWave Ticketing Extension Specification (for ticketing) - Visa Integrated Universal Data Storage V1.3 (for data storage)
  • VISA Asia Pacific WAVE 2

MasterCard

  • MasterCard PayPass M/Chip V3.0.3 (including Data Exchange)
  • MasterCard PayPass Mag-Stripe V3.3
  • NDOT over MasterCard - for transportation

MIR

  • MIR PS Contactless Terminal Kernel Specification (version 5.8)

Additional payment applications

Apple Pay

  • Android Pay
  • AMEX ExpressPay V3.0.1
  • Discover ZipNetwork V2.13
  • Interac Flash® 4

Mifare

  • Mifare Ultralight
  • Mifare Classic
  • Mifare DESFire

Transparent mode

  • ISO/IEC 14443 Type A - Transparent Proximity
  • ISO/IEC 14443 Type B - Transparent Proximity
  • ISO/IEC 15693 Vicinity (optional) - Transparent Vicinity
  • Transparent Mifare

Feature Specification

  • RF Carrier Frequency: 13.56 MHz
  • RF Output: 450mW
  • ISO/IEC 14443 A&B and Mifare: Full compliance
  • ISO/IEC 15693 Vicinity: Optional
  • Micro SIM push-push Interface
  • Communication Links: USB, RS232

USB:

  • 2.0 Full speed: CDC
  • Connectors: Standard mini-USB connector
  • USB only: Mini USB connector
  • Full interface: JST 10 pin P/N BM10B-ZPDSS

Indicators:

  • LEDs: Four programmable on-board LEDs
  • Buzzer: Multi tone differential drive buzzer
  • Electronic Board Power Requirements:
  • 8VDC – 45VDC: On-board switching power supply
  • 5VDC: From USB bus in USB only
  • Maximum Power consumption: 2W (RF signal ON)

Mechanical:

  • Dimensions: H – 0.66” (17 mm); W – 2.40” (61 mm); D – 3.07” (78 mm)
  • Weight: 125 gr.
  • Vibrations: 10 ÷ 200 Hz @ 2.0G

Temperature:

  • Operating: -20°C to 70°C (-4°F to 158°F)
Outdoor payment terminal "Streeter Pro"

In Master Sky you can buy street payment terminal "Streeter PRO Paynet". It has high water resistance, vandal resistance and modern design.

Street payment terminal "Streeter PRO Paynet" is designed for outdoor installation. It has a reinforced vandal-resistant housing, protected from moisture and dust, as well as equipped with a safe for the bill acceptor. Modern design and RGB backlight will distinguish the terminal among competitors.

Vandal resistant housing

Vandal-resistant case and special door opening mechanism exclude the possibility of tampering with the device from the outside.

Safe for bill acceptor

The bill acceptor is located in a separate area, which does not require access of service engineers, and the safe reliably protects cash from intruders.

LED lighting

Eye-catching and bright RGB backlighting sets the corporate style and draws the user's attention to the device.

Payment equipment

Coupon and coin acceptor allows you to make payment transactions with all types of cash.

Monitor with touch panel

The device interface and touch panel allows the user to make inquiries and enter data as quickly and conveniently as possible.

Check printing

High-quality thermal printer allows printing fiscal checks and issuing receipts for transactions.

Possibility of individual set of options and accessories

On your request we will install the necessary equipment to solve your business tasks.

Dimensions:

  • Width - 670 mm;
  • Depth - 520 mm;
  • Height - 2006 mm;
  • Weight - 162 kg.
Outdoor payment terminal "Streeter Light"

In "Master Sky" you can buy street payment terminal "Streeter Light". Reliable protection and silicone door seal provide its durability and weather protection, and ergonomic design simplifies service maintenance.

Streeter Light" payment kiosk is a well thought-out and reliable solution that fully meets all the standards of payment kiosks installed in high-traffic areas.

  • Reliable protection and a guarantee of a long service life
  • Ergonomic design
  • Space saving

Anitvandal enclosure

Anti-vandal case and special door opening mechanism exclude the possibility of tampering with the device from the outside.

Safe for bill acceptor

The bill acceptor is located in a separate area, which does not require access of service engineers, and the safe reliably protects cash from intruders.

RGB illumination

Equipping with LED backlighting helps to stand out favorably against the background of the general space of the room and competitors.

Payment equipment

Coupon and coin acceptor allows you to make payment transactions with any type of cash.

Monitor with touch panel

The device interface and touch panel allows the user to make inquiries and enter data as quickly and conveniently as possible.

Check printing

High-quality thermal printer allows you to print fiscal checks and issue receipts for transactions.

Possibility of individual set of accessories options

On your request we will install the necessary equipment to solve your business tasks.

Dimensions:

  • Width - 520 mm
  • Depth - 620 mm
  • Height - 1780 mm
  • Weight - 180 kg
The "APP PRO" payment kiosk Gray

In The Master Sky, you can buy the APP PRO Paynet payment kiosk. It combines reliability and modern design.

The APP Pro payment terminal combines a modern design that fits perfectly into any room. Thanks to a well thought-out design with a convenient arrangement of modules, the device occupies a minimum of space and provides easy maintenance.

  • Payment equipment
  • RGB Lighting
  • Touchscreen
  • Receipt printing
  • Personalization

Payment equipment

A bill acceptor and coin receiver allow for cash operations.

RGB Lighting

Your device will be highlighted among competitors and in the general space of the location.

Touchscreen

The device’s UI and touchscreen enable users to quickly form requests and enter the data.

Receipt printing

A high-quality thermoprinter can print fiscal receipts and issue bills for executed operations.

Personalization

All equipments can be installed according to your demands and your business needs.

Dimensions:

  • Width: 585 mm.
  • Height: 1369 mm
  • Depth: 351 mm
  • Power consumption: 310 W
  • Power supply: 220 V
The "APP PRO" payment kiosk White

In The Master Sky, you can buy the APP PRO Paynet payment kiosk. It combines reliability and modern design.

The APP Pro Paynet payment terminal combines a modern design that fits perfectly into any room. Thanks to a well thought-out design with a convenient arrangement of modules, the device occupies a minimum of space and provides easy maintenance.



  • Payment equipment
  • RGB Lighting
  • Touchscreen
  • Receipt printing
  • Personalization

Payment equipment

A bill acceptor and coin receiver allow for cash operations.

RGB Lighting

Your device will be highlighted among competitors and in the general space of the location.

Touchscreen

The device’s UI and touchscreen enable users to quickly form requests and enter the data.

Receipt printing

A high-quality thermoprinter can print fiscal receipts and issue bills for executed operations.

Personalization

All equipments can be installed according to your demands and your business needs.

Dimensions:

  • Width: 585 mm.
  • Height: 1369 mm
  • Depth: 351 mm
  • Power consumption: 310 W
  • Power supply: 220 V
Tobacco Cabinet "Smart"

In "Master Sky" you can buy Tobacco cabinet "Smart". This is an innovative solution for retail, replacing traditional tobacco cabinets. It automatically dispenses products and provides inventory management and sales analytics.

The Deposit machine (ADM)

In "Master Sky", you can buy the Deposit machine. A machine for an automated depositing of bills and packaging of cash into the collection bag.

The Deposit machine (ADM) - The Master SKY solutions for the banking industry cover almost the entire range of retail services of the bank, allowing to automate most of the operations, reducing the workload on the staff, or organize an automated branch of the bank. Acceptance and dispensing of the cash, issuance of the banking cards, lending, the depository - all of this is possible with The Master SKY equipment.

A machine for an automated depositing of bills and packaging of cash into the collection bag.



Features:

Recounting the bundle of bills of various nominal values with simultaneous verification of authenticity by 3 machine-readable features; Deposit of cash into the bag with the function of self-locking when removed; Printing the data on the transaction (number of deposited bill, nominal value, total amount of cash deposited).



Advantages:

  • Reliable steel case with multi-level break-in protection system;
  • Compact and economical;
  • High speed of counting and recognition of the bills;
  • Possibility of returning the bills in case of cancellation of the operation by the customer;
  • Storaging in the first class safe;
  • Patented self-locking system of the bag when removed;
  • Excluding the risk of receiving counterfeit bills;
  • Easy access to the safe during an encashment;
  • Easy maintenance of the kiosk due to the easy access to the kiosk modules;
  • Using quality components from the world's leading suppliers;
  • Deposit module: Glory DE-50

  • Receiving tray capacity: 300 bills

  • Recalculation rate: 600 bills per second

  • Capacity of the money bag: 10,000 bills

  • Monitor: 7" with a 4 mm multiple touch screen

  • Cheque printer: Custom TG-2480

  • Computer: AIMB-215D-S6B1E motherboard, MSata 60 Gb SSD drive.

  • Card reader : Sankyo ICT-3K7

  • Contactless card reader: UEM Mifare USB

  • Pin pad: ZT588FA

  • Uninterruptible Power Supply: APC Back-UPS ES

  • Modem: IRZ MC-55iT

  • Watchdog timer: Alarm2

  • Web camera: Logitech c270

  • Dimensions (h x w x d): 1640 x 602 x 685 mm
  • Weight: 260 kg
  • Power supply: 220-230 V / 50 Hz
  • Power consumption (max.): 500 W
  • Climatic version: +10 to +35
  • Relative humidity: 80%
Deposit machine (ADM)

In "Master Sky" you can buy a new generation deposit machine. The device is designed for automatic deposit of banknotes and reliable storage of cash until collection. Modern design with dynamic LED lighting emphasizes the technological solution and makes the machine visible at any point of service.

A deposit machine (ADM) is an advanced business device designed to automate the cash deposit process. It is ideal for use in offices and retail outlets where you need to deposit cash into your organization's account quickly and securely. With ADM, you can instantly deposit money into your company's account without having to visit a bank or wait for the cashier's office.

Advantages:

Instant crediting of money - effectively minimizes the time between cash acceptance and crediting;
Does not require the presence of personnel - autonomous operation of the device significantly reduces labor costs and simplifies cash management processes;
Universal scope of application - a wide range of applications includes retail, gas stations, pharmacies, car dealerships, cinemas, Horeca and shopping malls;
Security - the keys to the safe are not stored at the point of sale, eliminating the risk of unauthorized access to the collected funds.

Cassida banknote counter

High-tech currency counter and sorter, provides accurate detection of banknotes, including authentication.

Thermal check printer

Provides customers with paper proof of transaction, ensuring fast and high quality printing.

NFC reader

Enables contactless payments, speeding up the transaction process and enhancing user convenience.

PIN pad

Secure interface for entering PIN code, ensures the security of entering the customer's personal data

Secure pouch

Self-locking money pouch, provides secure transportation of funds, preventing unauthorized access to funds.

Possibility of individual set of options and bundles

Upon your request, we will install the necessary equipment to meet your business needs.

Pages
