BNR Advance Note Recycler

In The Master Sky, you can buy the BNR Advance Note Recycler.

The MEI® BNR Advance banknote recycler is a fresh approach to today’s world of cash management. Designed to simulate the accept and dispense ability of a cashier, the BNR Advance automates cash handling. This smart recycling process removes the need for loading, emptying, and reconciling cash. This BNR Advance lowers labor costs, loss exposure, and downtime.

The modular design configurations make it ideal for applications in self-checkout, retail payment, financial services, and transport markets. Paired with a coin recycler, the BNR Advance will provide your business with a reliable, closed loop cash management solution allowing your team to focus more on the customer and less on the cash.

Customer friendly. High speed, high security acceptance in a closed loop system

Minimize customer waiting time. Bulk dispense of up to 15 notes to speed up transactions

Reconciling made easy. Audit data is retrieved at the end of the day with all daily funds stored in a single locked cashbox

Flexible design options. Up to 3 dual recycler modules allows recycling of up to 6 denominations

Increased security. Validates notes with advanced recognition while storing banknotes in a single, locked cashbox

В режиме ожидания: 24 VDC (-10% + 20%), 0.5А

При пиковых нагрузках: 10А

Dimensions (H x W x D mm)

Closed: 604mm x 165mm x 275mm
604mm x 165mm x 336mm

Note validation

60 - 83mm Width 120 - 190mm Length

Interfaces Supported

USB

Denominations Recycled

Up to 6

Recycling Cassette Capacity

Each cassette: 2 denominations 30+60 bills capacity
Up to 3 cassettes (Total 270 bills recycled, 6 denominations)

Maximum Stacking Capacity

600 or 1400 bills

Note Memory Capacity

Up to 150 notes, four ways

Operating Temperature

0°C to 60°C

Storage Temperature

-40°C to 70°C

Operating Humidity

15-95% relative humidity

Firmware Updates

Remote software updates for firmware and note sets

Weight

up to 25.7kg (with Cashbox)

Compliance

UL / cUL recognized component to UL 756 and CSA 128
CB certification to IEC 60950

Acceptance Rate

98% or higher

Power Requirements

24VDC -10%/+20%

Current Consumption

Standby: 0.5A
Accepting: 8A

Bezels

B: plastic BZ / D: Flush metal BZ / S: Security Metal BZ

Maximum Length of Bill

190mm

Validation Sensors

Optical sensors

MEI GRYPHON coin acceptor

In Master Sky, you can buy the MEI GRYPHON coin acceptor.

With the Gryphon™ coin changer, CPI presents the next generation of coin handling technology for vending payment systems. This is the first of its kind to be equipped for connectivity and mobile diagnostics. Incorporating the latest technology in coin recognition with the best design elements from the CPI coin portfolio, Gryphon is equipped for improved reliability and lower cost of ownership.

Think fast and secure with this coin changer as it can dispense up to 6 coins at once, enabling faster patron throughput. The intelligent algorithms automatically detect the best coin distribution to minimize exact change situations. Offer effective cash management with this coin changer and minimize your cost of ownership.

Faster Coin Acceptance. Next generation, patented coin sensing technology ensures industry-leading speed and more secure coin recognition and dispensing

Increased reliability. Three motors ensure increased reliability and continuous performance, even in the case of a jammed motor

More tube capacity. 6 tubes provide operators with 12% extra capacity, enhanced configuration options, and increased flexibility

Easy updates and configuration. USB connectivity reduces at-machine update time

CPI Synq™ module compatibility. Wireless, on-site, mobile connectivity with the payment system to enable at-machine diagnostics, troubleshooting, and configuration for a reduction in service calls and higher machine up-time

Number of Tubes

6 tubes

Coin Diameter

Coins 15mm - 33mm in diameter

Coin Thickness

Coins 1.2mm - 3.3mm thick

Input speed

2 coins per second

Output Speed

6 coins per second

Interfaces Supported

Serial: MDB, MDB + Executive, MDB + BDV, JVI/VCCI, USB, Executive

Operating Temperature

-25°C to 60°C

Power Requirements

12 V DC - 24 V DC = Executive, 34 V DC = MDB

Tube/coin Level Recognition System

Acoustic, Sonar

Support Tools

STS Software
CPI Synq

Audit

USB, IrDA, Bluetooth

Acceptance Rate

>95%

Dimensions (mm)

371 x 138 x 80 mm

The Alberici AL55S coin acceptor

In The Master Sky, you can buy The Alberici AL55S coin acceptor for payment terminals, vending and car washes.

The Alberici AL55 is a reliable and high quality electronic coin acceptor Its mechanical and electronic technology guarantees a high level of recognition and discrimination of valid and counterfeit coins, as well as long-lasting high performances.
Programming software allows to clone the coin acceptor and move all configuration parameters in a simple and functional way, or alternatively it is possible to customize it at the user’s will.

High quality and secure coin acceptor. Equipped with 6 magnetic sensors and 4 optic pairs for a precise recognition of valid and counterfeit coins.

Identification technology: 6 magnetic sensors and 2 optical detectors, for a precise recognition of valid and counterfeit coins
High security level: 1 sequential optic pairs and 2 mechanical devices (wire-cutter and thread-ripper) to protect against fishing, frauds and tampers
Available interfaces: ccTalk Italy - Pulse/ccTalk modif.
Programming by one dip-switch row, or by PC Kit
16 programming channels can ensure an extraordinary versatility
32 bit ARM micro controller, 128KB Flash memory, “automotive” features, reliable in the most critical environments
Low power circuits produce low power consumption
Manual programming and single acceptance coin disabling by Dip-switch
