Heating for the kiosk 250W

In The Master Sky, you can buy heating for the kiosk. The fan heater uses high-quality heat-resistant construction plastic, which makes it safe and reliable.

Heating for the kiosk has high productivity and is able to heat even large electrical devices.

The design of the fan heater allows the free orientation of the fan heater when mounted on a DIN-rail, while the self-adjusting posistor-type heating element ensures safe use.

The fan heater uses high-quality heat-resistant construction plastic, which makes it safe and reliable.

Power: 250 W
Supply voltage: 230V AC
Inrush current of the heater: 3.5 A
Fan capacity, m3/h: 27
Working temperature ° C: -20...+70
Fan life cycle: 70,000 hours
Degree of protection: IP20
Mounting: DIN clip (35mm)
Body material: corresponds to UL-94 V0

Dimensions: 75x99x70

Weight: 0.285

Watchdog timer

In The Master Sky, you can buy a watchdog timer for the kiosk. It is designed for remoted physical power management of payment kiosk devices.

Watchdog timer - designed for remoted physical power management of payment kiosk devices. The timer is connected via a USB port and is defined by the operating system as a virtual COM port. By sending certain commands to the COM port, it is possible to physically break the power supply to the kiosk devices.

In this case:

Modem;
Bill acceptor;
System block;

The Logitech C310 web camera

In The Master Sky, you can buy the Logitech C310 HD web camera. It features a widescreen mode, 720p resolution at 30 frames per second.

The Logitech C310 HD webcam uses a widescreen mode, 720p resolution at 30 frames per second. Automatic Light Correction ensures natural color reproduction even in low lighting conditions.


Matrix: CMOS
Resolution (video): 1280x720
Interpolated resolution in megapixels (photo): 5 million pixels.

Main parameters:

Connection: USB 2.0
Microphone: built-in
Compatible operating systems: Windows XP/Vista/7

Security alarm for the kiosk

In The Master Sky, you can buy security alarms for kiosks. The set includes 2 key chains, each with 4 buttons.

Security alarm for kiosks is an excellent modern alarm system for a reasonable price, which is equipped with a simple set of standard functions. The set includes 2 key chains, each with 4 buttons. Dynamic code with anti-scanning, shock sensor has two levels of triggering.

Type: One-sided (without feedback).
GPS module: No
GSM module: No
Dialog code: No
Dynamic code: Yes
Antigrabber: Yes
Range of action: 200 m

The kit includes:

Control unit
2 key chains with buttons
Impact sensor
Siren
Indication LED
Wire set

Heating for the kiosk with a temperature sensor

In The Master Sky, you can buy a heater for the kiosk with a temperature sensor.

Heating for the kiosk with a temperature sensor.

Dimensions: 12.1 * 7.4 * 3.5 cm.

Stickers for payment kiosks

In The Master Sky, you can buy stickers for payment kiosks.

Bright stickers with the latest information for your payment kiosk. The set of stickers consists of 8 pieces.

The ITL IF17 converter

In The Master Sky, you can buy the ITL IF17 converter.

The ITL IF17 converter.

The ITL IF5 converter

In The Master Sky, you can buy the ITL IF5 converter.

Interface converter, IF5 = MDB interface (Multi Drop-Bus)

The Custom TK302 thermal printer

In The Master Sky, you can buy the Custom TK302 compact printer for printing tickets. The printer can be equipped with an optional barcode scanner for checking tickets with pre-made barcodes and numerous RFID modules for HF and UHF.

The Custom TK302 is the newest ticket printer on the market. The printer can be equipped with an optional barcode scanner for checking tickets with pre-made barcodes and numerous RFID modules for HF and UHF. With the TK302 barcode scanner, it is suitable for all applications with a high risk of fraud and for increased access protection. The barcode scanner is located inside the printer, ensuring a secure, real-time scanning process.

Ethernet and web server for printing and remote configuration
Printing speed up to 200 mm / s
Tickets of various widths from 20 to 82.5 mm
Ticket density (density): 80 to 255 g/m²
Built-in display 2 lines
Automatic durable cutter for 2 million cuts
Powerful 32-bit processor from 266 MHz
RAM up to 32 MB on 32 MB flash memory
SD expansion slot for an additional 2 GB memory
SW COM / USB Virtual Emulator
Printing 1D and 2D bar codes: UPC-A, UPC-E, EAN13, EAN8, CODE39, ITF, CODABAR, CODE93, CODE128, CODE32, PDF417, DATAMATRIX, AZTEC, QR CODE
RS232 + USB + Ethernet interface
Sensors: Optical upper and lower sensors fully adjustable for any ticket width. Ticket Presence Sensor
Via a 2 Gb SD card or 8 Mb high capacity USB memory, you can easily download True Font fonts and logos by dragging and dropping them and installing them directly.
External power supply - detachable for greater mounting flexibility
Self-installable driver for Win XP/Vista/7, OPOS in Java and .NET and Driver Linux

Dimensions: 252.1 x 192.6 x 216 mm

Weight: 4 kg

Technical specification

The Custom TK180 printer

In The Master Sky, you can buy the Custom TK180 compact printer for printing tickets.

The Custom TK180 compact printer for printing tickets. Prints information (barcodes, 2D codes, QR codes, numbers, and letters) at speeds up to 200 mm/sec. Performs a thermal transfer printing method. Resolution supported: 203 dpi or 304 dpi.

The printer is equipped with an automatic sensor calibration, which allows the first ticket printed to be used and makes printing waste-free. Due to its small size, it easily fits on a table, which allows it to be used in small booths at events, railway ticket offices and airport check-in desks. It can print on the receipt paper. Supports True Font in all languages. Applies 1D and 2D barcodes (PDF417, DATAMATRIX, AZTEC, QR CODE).

Model Features:

Built-in automatic cutter;
Long life cycle of the thermal printing head up to 100.000.000 pulses;
Maximum external roll diameter up to 200 mm
Supports up to 8 MB of external Flash memory.

Printing method: Thermal with a fixed head
Number of points: 8 points/mm at 200 t/d or 12 points/mm at 300 t/d
Resolution: 200 t/d or 300 t/d
Printing speed (mm/sec): 200 mm/sec at 200 t/d or 150 mm/sec at 300 t/d
Character sets: PC437, PC850, PC860, PC863, PC865, International
Supported bar codes: UPC-A, UPC-E, EAN13,EAN8, CODE39, ITF, CODABAR, CODE93, CODE128, CODE32, PDF417, DATAMATRIX, AZTEC, QRCODE
Font styles: Height/width from 1 to 8, bold, negative, underline, italics
Printing direction: straight, 90°, 180°, 270°
Paper width: 20 mm to 82.5 mm
Paper density: 70 to 255 g/m²
Paper thickness: Max. 270 µm
Printing width: 80 mm
Roll dimensions: Outer diameter 200 mm, inner core 25 mm, paper not fixed to the inner core of the roll
Emulation: CUSTOM/POS, SVELTA
Interfaces: RS232 / USB / ETHERNET
Data buffer: 16 kbytes
Flash memory: 1 Mbyte internal + 8 Mbyte external (of which 4 Mbytes are available to the user)
RAM memory: 128 kbytes internal + 8 Mbytes external
Graphics memory: "Drag and drop" graphics and logos
Driver: WHQL: Win XP, Win Vista,7, 8 (compatible with 32/64-bit version), Linux Driver (C.U.P.S.) compatible with 32/64-bit version, all releases / all cores, Android, iOS
Power supply: 24 V DC ±10%, 110 V AC
Average absorption: 1.5A (12.5% density)
Average MTBF: 113,000 hours (electronic board)
Printing head life cycle: 100 km / 100 million pulses
Automatic cutter resource: 1.000.000 cuts
Working temperature: -10°C + 60°C ±10%

Dimensions: 130 x 185.9 x 118.9 mm

Weight: 1.9 kg

Technical specification
